Water Softener Plant Manufacturer

Hard water leaves white scale on taps, tiles, geysers and boilers, reduces soap lather, shortens the life of pipes and appliances and increases fuel consumption in boilers. Intellect Aqua designs and manufactures water softener plants for apartments, hotels, laundries, hospitals, boilers and industrial facilities across Tamil Nadu, using high-quality ion exchange resin and automatic multiport valves.

How a water softener works

A water softener uses ion exchange to remove calcium (Ca²⁺) and magnesium (Mg²⁺) ions — the hardness-causing minerals — and replaces them with sodium (Na⁺) ions from a resin bed. The softened water passes through pipes and equipment without forming scale.

  • Hard water enters the FRP pressure vessel containing cation exchange resin.
  • Resin attracts Ca²⁺ and Mg²⁺ and releases Na⁺ ions into the water.
  • Soft, scale-free water is supplied to taps, boilers, cooling towers and laundry.
  • When resin is exhausted, it is regenerated automatically with a brine (salt + water) solution.
  • Regeneration takes 1–2 hours; the system then returns to service.
  • Only common salt (NaCl) is consumed — no acids or alkalis needed.

Features of our water softeners

  • Automatic multiport valve with timer-based regeneration
  • Built-in self-cleaning during backwash cycle
  • Superior water flow rate with high-capacity resin
  • FRP pressure vessel — corrosion-free, light and durable
  • Fully automated — no manual intervention needed
  • Design customised to raw water hardness and flow
  • Factory-built and 24-hour tested before dispatch

Where water softeners are used

  • Apartments and gated communities
  • Hotels, resorts and laundries
  • Boiler feed water pre-treatment
  • Cooling towers to prevent scale build-up
  • Textile, food and pharma industries
  • Hospitals and healthcare facilities
  • RO plant pre-treatment — reduces antiscalant and membrane load

Softener or RO — which do you need?

  • Softener: best when only hardness is a problem. Does not reduce TDS, fluoride or nitrates. Softened water is not for drinking unless also RO-treated.
  • RO plant: reduces TDS, hardness, bacteria, fluoride and most other impurities. Suitable for drinking water.
  • Softener + RO: for very high-hardness borewell water. Softener protects RO membranes from scaling and extends membrane life.

What decides the price

  • Raw water hardness (mg/L as CaCO₃)
  • Flow rate and daily output required (LPH or KLD)
  • Resin volume and vessel size
  • Manual vs fully automatic multiport valve
  • Number of units (standby vessel or duplex system)
